Application Interfaces

AbsCtrlIntvg

ABS Control Intervening

Antilock Braking System's (ABS) control is active (at least one wheel)

0 NoCtrl

1 InCtrl

AbsCtrlOvrdnByRsc

ABS Control Overridden by RSC

Flag indicating Roll Stability Control (RSC) brake torque overrides Antilock Braking System (ABS). This enables RSC to request more braking torque than ABS. For wheel lift detection. (Vector of 4)

AbsFlgActv

Antilock Braking System (ABS) Control Active

Antilock Braking System (ABS) control is active (at least one wheel) - 0 = No wheel is in Antilock Braking System (ABS) control - 1 = At least one wheel is in Antilock Braking System (ABS) control

0 NoCtrl

1 InCtrl

AccActv

Adaptive Cruise Control Active

Switch operated by driver to make Adaptive Cruise Control stand-by mode is on.

0 Off

1 On

2 Err

AccCtrlActv

Adaptive Cruise Control Control Active

Adaptive Cruise Control is engaged and active. This information is used for display feedback for driver as well.

0 Off

1 On

2 Err

AccVehDetdIndcn

Adaptive Cruise Control Vehicle Detected Indication

Target vehicle for Adaptive Cruise Control is detected. This information is used for display feedback for driver.

0 NotDetd

1 Detd

AcsKeyls

Keyless Access

Request of central locking from keyless access

AcsOfSeatRe

Rear Seat Access

Indicates the user's demand for access to the rear seats. For cars with only 2 front doors there might be a feature provided called like "easy entry", which facilitates the access to the rear seats. This is usually achieved by means of moving the according front seat (driver side or passenger side) or seat back.

0 Idle

1 ActvtEntryEasyFrnt

2 RelsEntryEasyFrnt

3 ActvtEntryEasyRe

4 RelsEntryEasyRe

AcsOfSeatReByDrvrSeat

Rear Seat Access

Indicates the user's demand for access to the rear seats. For cars with only 2 front doors there might be a feature provided called like "easy entry", which facilitates the access to the rear seats. This is usually achieved by means of moving the according front seat (driver side or passenger side) or seat back.

0 Idle

1 ActvtEntryEasyFrnt

2 RelsEntryEasyFrnt

3 ActvtEntryEasyRe

4 RelsEntryEasyRe

AcsOfSeatReByPassSeat

Rear Seat Access

Indicates the user's demand for access to the rear seats. For cars with only 2 front doors there might be a feature provided called like "easy entry", which facilitates the access to the rear seats. This is usually achieved by means of moving the according front seat (driver side or passenger side) or seat back.

0 Idle

1 ActvtEntryEasyFrnt

2 RelsEntryEasyFrnt

3 ActvtEntryEasyRe

4 RelsEntryEasyRe

AcsOfSeatReBySeatRowFirstMid

Rear Seat Access

Indicates the user's demand for access to the rear seats. For cars with only 2 front doors there might be a feature provided called like "easy entry", which facilitates the access to the rear seats. This is usually achieved by means of moving the according front seat (driver side or passenger side) or seat back.

0 Idle

1 ActvtEntryEasyFrnt

2 RelsEntryEasyFrnt

3 ActvtEntryEasyRe

4 RelsEntryEasyRe

AcsOfSeatReBySeatRowSecLe

Rear Seat Access

Indicates the user's demand for access to the rear seats. For cars with only 2 front doors there might be a feature provided called like "easy entry", which facilitates the access to the rear seats. This is usually achieved by means of moving the according front seat (driver side or passenger side) or seat back.

0 Idle

1 ActvtEntryEasyFrnt

2 RelsEntryEasyFrnt

3 ActvtEntryEasyRe

4 RelsEntryEasyRe

AcsOfSeatReBySeatRowSecMid

Rear Seat Access

Indicates the user's demand for access to the rear seats. For cars with only 2 front doors there might be a feature provided called like "easy entry", which facilitates the access to the rear seats. This is usually achieved by means of moving the according front seat (driver side or passenger side) or seat back.

0 Idle

1 ActvtEntryEasyFrnt

2 RelsEntryEasyFrnt

3 ActvtEntryEasyRe

4 RelsEntryEasyRe

AcsOfSeatReBySeatRowSecRi

Rear Seat Access

Indicates the user's demand for access to the rear seats. For cars with only 2 front doors there might be a feature provided called like "easy entry", which facilitates the access to the rear seats. This is usually achieved by means of moving the according front seat (driver side or passenger side) or seat back.

0 Idle

1 ActvtEntryEasyFrnt

2 RelsEntryEasyFrnt

3 ActvtEntryEasyRe

4 RelsEntryEasyRe

AcsOfSeatReBySeatRowThrdLe

Rear Seat Access

Indicates the user's demand for access to the rear seats. For cars with only 2 front doors there might be a feature provided called like "easy entry", which facilitates the access to the rear seats. This is usually achieved by means of moving the according front seat (driver side or passenger side) or seat back.

0 Idle

1 ActvtEntryEasyFrnt

2 RelsEntryEasyFrnt

3 ActvtEntryEasyRe

4 RelsEntryEasyRe

AcsOfSeatReBySeatRowThrdMid

Rear Seat Access

Indicates the user's demand for access to the rear seats. For cars with only 2 front doors there might be a feature provided called like "easy entry", which facilitates the access to the rear seats. This is usually achieved by means of moving the according front seat (driver side or passenger side) or seat back.

0 Idle

1 ActvtEntryEasyFrnt

2 RelsEntryEasyFrnt

3 ActvtEntryEasyRe

4 RelsEntryEasyRe

AcsOfSeatReBySeatRowThrdRi

Rear Seat Access

Indicates the user's demand for access to the rear seats. For cars with only 2 front doors there might be a feature provided called like "easy entry", which facilitates the access to the rear seats. This is usually achieved by means of moving the according front seat (driver side or passenger side) or seat back.

0 Idle

1 ActvtEntryEasyFrnt

2 RelsEntryEasyFrnt

3 ActvtEntryEasyRe

4 RelsEntryEasyRe

ActrBodyLvlSt

Actuator Body Level Status

Status provided by body level actuator system

0 Off

1 On

2 Err

ActrBodyLvlSts

Actuator Body Level Status

Status provided by body level actuator system

0 Off

1 On

2 Err

ActrBrkOnDmdFailrInRsc

Actuator Brake on Demand Failure in RSC

Brake actuator failure status with respect to availability for brake-on-demand functions related to Roll Stability Control.

0 NoFlt

1 Flt

ActrBrkOnDmdFailrInSsm

Actuator Brake on Demand Failure in Stand Still Management

Brake actuator failure status with respect to availability for brake-on-demand functions related to the Stand Still Manager.

0 NoFlt

1 Flt

ActrBrkOnDmdFailrInVlc

Actuator Brake on Demand Failure in Vehicle Longitudinal Control (VLC)

Brake actuator failure status with respect to availability for brake-on-demand functions related to Vehicle Longitudinal Control.

0 NoFlt

1 Flt

ActrStConsoldAtDftlForTqTrf

Actuator Status Consolidated at Differential for Torque Transfer

Status of the Transfer Case Actuator.

0 Flt

1 NoFlt

2 Lockd

ActrStsActAtDftlForTqTrf

Actuator Status Actual at Differential for Torque Transfer

Status of the Transfer Case Actuator.

0 Flt

1 NoFlt

2 Lockd

ActvSuspMod

Active Suspension Mode

Active suspension mode for display to the driver and provided to other systems

0 SuspModStd

1 SuspModCmft

2 SuspModSpt

3 SuspModOffroad

ActvSuspSt

Active Suspension Status

Status provided by active suspension system

0 Off

1 On

2 Err

ActvSuspSts

Active Suspension Status

Status provided by active suspension system

0 Off

1 On

2 Err

ActvnOfWshngCmd

Activation of Washing Command

Command for washing

0 Off

1 On

ActvnOfWshngCmdOfWshrFrnt

Activation of Washer Front

Users demand for front window washing on/off

0 Off

1 On

ActvnOfWshngCmdOfWshrHdlamp

Activation of Washer Head Lamp

User's demand for headlamp window washing on/off

0 Off

1 On

ActvnOfWshngCmdOfWshrRe

Activation of Washer Rear

User's demand for rear window washing on/off

0 Off

1 On

ActvnTintg

Tinting Activation

Command to activate/deactivate the tinting of the mirror.

ActvtOfActrAirbFrntAtDrvr

Activate of Actuator Airbag Front at Driver

Activate front airbag to protect driver

0 NotReqd

1 Reqd

ActvtOfActrAirbFrntAtPass

Activate of Actuator Airbag Front at Passenger

Activate front airbag to protect passenger

0 NotReqd

1 Reqd

ActvtOfActrAirbFrntAtRowFirstMid

Activate of Actuator Airbag Front at Row First Middle

Activate front airbag to protect occupant at first row middle seat

0 NotReqd

1 Reqd

ActvtOfActrAirbSideAtDrvr

Activate of Actuator Airbag Side at Driver

Activate side airbag at driver position to protect driver at side impact situations

0 NotReqd

1 Reqd

ActvtOfActrAirbSideAtPass

Activate of Actuator Airbag Side at Passenger

Activate side airbag at passenger position to protect passenger at side impact situations

0 NotReqd

1 Reqd

ActvtOfActrAirbSideAtRowSecLe

Activate of Actuator Airbag Side at Row Second Left

Activate side airbag at second row, left side to protect occupant at side impact situations

0 NotReqd

1 Reqd

ActvtOfActrAirbSideAtRowSecRi

Activate of Actuator Airbag Side at Row Second Right

Activate side airbag at second row, right side to protect occupant at side impact situations

0 NotReqd

1 Reqd

ActvtOfActrAirbSideAtRowThrdLe

Activate of Actuator Airbag Side at Row Third Left

Activate side airbag at third row, left side to protect occupant at side impact situations

0 NotReqd

1 Reqd

ActvtOfActrAirbSideAtRowThrdRi

Activate of Actuator Airbag Side at Row Thrid Right

Activate side airbag at third row, right side to protect occupant at side impact situations

0 NotReqd

1 Reqd

ActvtOfActrAnchrfitgTensnrAtDrvr

Activate of Actuator Anchorfitting Tensioner at Driver

Activate anchor fitting tensioner at driver position

0 NotReqd

1 Reqd

ActvtOfActrAnchrfitgTensnrAtPass

Activate of Actuator Anchorfitting Tensioner at Passenger

Activate anchor fitting tensioner at passenger position

0 NotReqd

1 Reqd

ActvtOfActrAnchrfitgTensnrAtRowFirstMid

Activate of Actuator Anchorfitting Tensioner at Row First Middle

Activate anchor fitting tensioner at seat in first row, middle position

0 NotReqd

1 Reqd

ActvtOfActrAnchrfitgTensnrAtRowSecLe

Activate of Actuator Anchorfitting Tensioner at Row Second Left

Activate anchor fitting tensioner at seat in second row, left position

0 NotReqd

1 Reqd

ActvtOfActrAnchrfitgTensnrAtRowSecMid

Activate of Actuator Anchorfitting Tensioner at Row Second Middle

Activate anchor fitting tensioner at seat in second row, middle position

0 NotReqd

1 Reqd

ActvtOfActrAnchrfitgTensnrAtRowSecRi

Activate of Actuator Anchorfitting Tensioner at Row Second Right

Activate anchor fitting tensioner at seat in second row, right position

0 NotReqd

1 Reqd

ActvtOfActrAnchrfitgTensnrAtRowThrdLe

Activate of Actuator Anchorfitting Tensioner at Row Third Left

Activate anchor fitting tensioner at seat in third row, left position

0 NotReqd

1 Reqd

ActvtOfActrAnchrfitgTensnrAtRowThrdMid

Activate of Actuator Anchorfitting Tensioner at Row Third Middle

Activate anchor fitting tensioner at seat in third row, middle position

0 NotReqd

1 Reqd

ActvtOfActrAnchrfitgTensnrAtRowThrdRi

Activate of Actuator Anchorfitting Tensioner at Row Third Right

Activate anchor fitting tensioner at seat in third row, right position

0 NotReqd

1 Reqd

ActvtOfActrAntisubCushAtDrvr

Activate of Actuator Antisubmarine Cushion at Driver

Activate Antisubmarine cushion at driver position

0 NotReqd

1 Reqd

ActvtOfActrAntisubCushAtPass

Activate of Actuator Antisubmarine Cushion at Passenger

Activate Antisubmarine cushion at passenger position

0 NotReqd

1 Reqd

ActvtOfActrAntisubCushAtRowFirstMid

Activate of Actuator Antisubmarine Cushion at Row First Middle

Activate Antisubmarine cushion at seat in first row, middle position

0 NotReqd

1 Reqd

ActvtOfActrAntisubCushAtRowSecLe

Activate of Actuator Antisubmarine Cushion at Row Second Left

Activate Antisubmarine cushion at seat in second row, left position

0 NotReqd

1 Reqd

ActvtOfActrAntisubCushAtRowSecMid

Activate of Actuator Antisubmarine Cushion at Row Second Middle

Activate Antisubmarine cushion at seat in second row, middle position

0 NotReqd

1 Reqd

ActvtOfActrAntisubCushAtRowSecRi

Activate of Actuator Antisubmarine Cushion at Row Second Right

Activate Antisubmarine cushion at seat in second row, right position

0 NotReqd

1 Reqd

ActvtOfActrAntisubCushAtRowThrdLe

Activate of Actuator Antisubmarine Cushion at Row Third Left

Activate Antisubmarine cushion at seat in third row, left position

0 NotReqd

1 Reqd

ActvtOfActrAntisubCushAtRowThrdMid

Activate of Actuator Antisubmarine Cushion at Row Third Middle

Activate Antisubmarine cushion at seat in third row, middle position

0 NotReqd

1 Reqd

ActvtOfActrAntisubCushAtRowThrdRi

Activate of Actuator Antisubmarine Cushion at Row Third Right

Activate Antisubmarine cushion at seat in third row, right position

0 NotReqd

1 Reqd

ActvtOfActrAtApilLeForPedProtn

Activate of Actuator at Apillar Left for Pedestrian Protection

activate actuator at left A-pillar to protect pedestrian

0 NotReqd

1 Reqd

ActvtOfActrAtApilRiForPedProtn

Activate of Actuator at Apillar Right for Pedestrian Protection

activate actuator at right A-pillar to protect pedestrian

0 NotReqd

1 Reqd

ActvtOfActrAtBmpForPedProtn

Activate of Actuator at Bumper for Pedestrian Protection

activate bumper actuator to protect pedestrian

0 NotReqd

1 Reqd

ActvtOfActrAtHoodForPedProtn

Activate of Actuator at Hood for Pedestrian Protection

activate hood actuator to protect pedestrian

0 NotReqd

1 Reqd

ActvtOfActrAtRoofForPedProtn

Activate of Actuator at Roof for Pedestrian Protection

activate actuator at roof to protect pedestrian

0 NotReqd

1 Reqd

ActvtOfActrBattCutOff

Activate of Actuator Battery Cut Off

Cut off of battery in case of crash

0 NotReqd

1 Reqd

ActvtOfActrBltLimrAtDrvr

Activate of Actuator Belt Limiter at Driver

Activate belt limiter at driver position

0 NotReqd

1 Reqd

ActvtOfActrBltLimrAtPass

Activate of Actuator Belt Limiter at Passenger

Activate belt limiter at passenger position

0 NotReqd

1 Reqd

ActvtOfActrBltLimrAtRowFirstMid

Activate of Actuator Belt Limiter at Row First Middle

Activate belt limiter at seat in first row, middle position

0 NotReqd

1 Reqd

ActvtOfActrBltLimrAtRowSecLe

Activate of Actuator Belt Limiter at Row Second Left

Activate belt limiter at seat in second row, left position

0 NotReqd

1 Reqd

ActvtOfActrBltLimrAtRowSecMid

Activate of Actuator Belt Limiter at Row Second Middle

Activate belt limiter at seat in second row, middle position

0 NotReqd

1 Reqd

ActvtOfActrBltLimrAtRowSecRi

Activate of Actuator Belt Limiter at Row Second Right

Activate belt limiter at seat in second row, right position

0 NotReqd

1 Reqd

ActvtOfActrBltLimrAtRowThrdLe

Activate of Actuator Belt Limiter at Row Third Left

Activate belt limiter at seat in third row, left position

0 NotReqd

1 Reqd

ActvtOfActrBltLimrAtRowThrdMid

Activate of Actuator Belt Limiter at Row Third Middle

Activate belt limiter at seat in third row, middle position

0 NotReqd

1 Reqd

ActvtOfActrBltLimrAtRowThrdRi

Activate of Actuator Belt Limiter at Row Third Right

Activate belt limiter at seat in third row, right position

0 NotReqd

1 Reqd

ActvtOfActrBltTensnrAtDrvr

Activate of Actuator Belt Tensioner at Driver

Activate belt tensioner at driver position

0 NotReqd

1 Reqd

ActvtOfActrBltTensnrAtPass

Activate of Actuator Belt Tensioner at Passenger

Activate belt tensioner at passenger position

0 NotReqd

1 Reqd

ActvtOfActrBltTensnrAtRowFirstMid

Activate of Actuator Belt Tensioner at Row First Middle

Activate belt tensioner at seat in first row, middle position

0 NotReqd

1 Reqd

ActvtOfActrBltTensnrAtRowSecLe

Activate of Actuator Belt Tensioner at Row Second Left

Activate belt tensioner at seat in second row, left position

0 NotReqd

1 Reqd

ActvtOfActrBltTensnrAtRowSecMid

Activate of Actuator Belt Tensioner at Row Second Middle

Activate belt tensioner at seat in second row, middle position

0 NotReqd

1 Reqd

ActvtOfActrBltTensnrAtRowSecRi

Activate of Actuator Belt Tensioner at Row Second Right

Activate belt tensioner at seat in second row, right position

0 NotReqd

1 Reqd

ActvtOfActrBltTensnrAtRowThrdLe

Activate of Actuator Belt Tensioner at Row Third Left

Activate belt tensioner at seat in third row, left position

0 NotReqd

1 Reqd

ActvtOfActrBltTensnrAtRowThrdMid

Activate of Actuator Belt Tensioner at Row Third Middle

Activate belt tensioner at seat in third row, middle position

0 NotReqd

1 Reqd

ActvtOfActrBltTensnrAtRowThrdRi

Activate of Actuator Belt Tensioner at Row Third Right

Activate belt tensioner at seat in third row, right position

0 NotReqd

1 Reqd

ActvtOfActrBucRtrctrAtDrvr

Activate of Actuator Buckle Retractor at Driver

Activate buckle retractor at driver position

0 NotReqd

1 Reqd

ActvtOfActrBucRtrctrAtPass

Activate of Actuator Buckle Retractor at Passenger

Activate buckle retractor at passenger position

0 NotReqd

1 Reqd

ActvtOfActrBucRtrctrAtRowFirstMid

Activate of Actuator Buckle Retractor at Row First Middle

Activate buckle retractor at seat in first row, middle position

0 NotReqd

1 Reqd

ActvtOfActrBucRtrctrAtRowSecLe

Activate of Actuator Buckle Retractor at Row Second Left

Activate buckle retractor at seat in second row, left position

0 NotReqd

1 Reqd

ActvtOfActrBucRtrctrAtRowSecMid

Activate of Actuator Buckle Retractor at Row Second Middle

Activate buckle retractor at seat in second row, middle position

0 NotReqd

1 Reqd

ActvtOfActrBucRtrctrAtRowSecRi

Activate of Actuator Buckle Retractor at Row Second Right

Activate buckle retractor at seat in second row, right position

0 NotReqd

1 Reqd

ActvtOfActrBucRtrctrAtRowThrdLe

Activate of Actuator Buckle Retractor at Row Third Left

Activate buckle retractor at seat in third row, left position

0 NotReqd

1 Reqd

ActvtOfActrBucRtrctrAtRowThrdMid

Activate of Actuator Buckle Retractor at Row Third Middle

Activate buckle retractor at seat in third row, middle position

0 NotReqd

1 Reqd

ActvtOfActrBucRtrctrAtRowThrdRi

Activate of Actuator Buckle Retractor at Row Third Right

Activate buckle retractor at seat in third row, right position

0 NotReqd

1 Reqd

ActvtOfActrCurtAirbAtLe

Activate of Actuator Curtain Airbag at Left

Activate left curtain airbag actuator to protect occupants at side impact

0 NotReqd

1 Reqd

ActvtOfActrCurtAirbAtRi

Activate of Actuator Curtain Airbag at Right

Activate right curtain airbag actuator to protect occupants at side impact

0 NotReqd

1 Reqd

ActvtOfActrFuCutOff

Activate of Actuator Fuel Cut Off

Cut off of fuel in case of crash

0 NotReqd

1 Reqd

ActvtOfActrHdrestAtDrvr

Activate of Actuator Headrest at Driver

Activate headrest at driver seat position

0 NotReqd

1 Reqd

ActvtOfActrHdrestAtPass

Activate of Actuator Headrest at Passenger

Activate headrest at passenger seat position

0 NotReqd

1 Reqd

ActvtOfActrHdrestAtRowFirstMid

Activate of Actuator Headrest at Row First Middle

Activate headrest at middle seat position of first row

0 NotReqd

1 Reqd

ActvtOfActrHdrestAtRowSecLe

Activate of Actuator Headrest at Row Second Left

Activate headrest at left seat position of second row

0 NotReqd

1 Reqd

ActvtOfActrHdrestAtRowSecMid

Activate of Actuator Headrest at Row Second Middle

Activate headrest at middle seat position of second row

0 NotReqd

1 Reqd

ActvtOfActrHdrestAtRowSecRi

Activate of Actuator Headrest at Row Second Right

Activate headrest at right seat position of second row

0 NotReqd

1 Reqd

ActvtOfActrHdrestAtRowThrdLe

Activate of Actuator Headrest at Row Third Left

Activate headrest at left seat position of third row

0 NotReqd

1 Reqd

ActvtOfActrHdrestAtRowThrdMid

Activate of Actuator Headrest at Row Third Middle

Activate headrest at middle seat position of third row

0 NotReqd

1 Reqd

ActvtOfActrHdrestAtRowThrdRi

Activate of Actuator Headrest at Row Third Right

Activate headrest at right seat position of third row

0 NotReqd

1 Reqd

ActvtOfActrKneeProtnAtDrvr

Activate of Actuator Knee Protection at Driver

Activate knee protection actuator to protect drivers knee

0 NotReqd

1 Reqd

ActvtOfActrKneeProtnAtPass

Activate of Actuator Knee Protection at Passenger

Activate knee protection actuator to protect passenger knee

0 NotReqd

1 Reqd

ActvtOfActrKneeProtnAtRowFirstMid

Activate of Actuator Knee Protection at Row First Middle

Activate knee protection actuator to protect occupant knee at first row middle seat

0 NotReqd

1 Reqd

ActvtOfActrPelvProtnAtDrvr

Activate of Actuator Pelvis Protection at Driver

Activate pelvis protection actuator at driver position

0 NotReqd

1 Reqd

ActvtOfActrPelvProtnAtPass

Activate of Actuator Pelvis Protection at Passenger

Activate pelvis protection actuator at passenger position

0 NotReqd

1 Reqd

ActvtOfActrPelvProtnAtRowSecLe

Activate of Actuator Pelvis Protection at Row Second Left

Activate pelvis protection actuator at second row on left side

0 NotReqd

1 Reqd

ActvtOfActrPelvProtnAtRowSecRi

Activate of Actuator Pelvis Protection at Row Second Right

Activate pelvis protection actuator at second row at right side

0 NotReqd

1 Reqd

ActvtOfActrPelvProtnAtRowThrdLe

Activate of Actuator Pelvis Protection at Row Third Left

Activate pelvis protection actuator at third row at left side

0 NotReqd

1 Reqd

ActvtOfActrPelvProtnAtRowThrdRi

Activate of Actuator Pelvis Protection at Row Third Right

Activate pelvis protection actuator at third row at right side

0 NotReqd

1 Reqd

ActvtOfActrRollbarAtLe

Activate of Actuator Rollbar at Left

Activate safety rollbar on left side (usually on roll or pitch over situations) to protect occupants on convertibles

0 NotReqd

1 Reqd

ActvtOfActrRollbarAtRi

Activate of Actuator Rollbar at Right

Activate safety rollbar on right side (usually on roll or pitch over situations) to protect occupants on convertibles

0 NotReqd

1 Reqd

ActvtOfActrThoraxAirbAtDrvr

Activate of Actuator Thorax Airbag at Driver

Activate head/thorax airbag between driver and compartment

0 NotReqd

1 Reqd

ActvtOfActrThoraxAirbAtPass

Activate of Actuator Thorax Airbag at Passenger

Activate head/thorax airbag between passenger and compartment

0 NotReqd

1 Reqd

ActvtOfActrThoraxAirbAtRowFirstMidToDrvr

Activate of Actuator Thorax Airbag at Row First Middle to Driver

Activate head/thorax airbag in first row in between driver and middle seating position or driver and passenger

0 NotReqd

1 Reqd

ActvtOfActrThoraxAirbAtRowFirstMidToPass

Activate of Actuator Thorax Airbag at Row First Middle to Passenger

Activate head/thorax airbag in first row in between passenger and middle seating position

0 NotReqd

1 Reqd

ActvtOfActrThoraxAirbAtRowSecLe

Activate of Actuator Thorax Airbag at Row Second Left

Activate head/thorax airbag in second row at the left

0 NotReqd

1 Reqd

ActvtOfActrThoraxAirbAtRowSecMidLe

Activate of Actuator Thorax Airbag at Row Second Middle Left

Activate head/thorax airbag at second row in between middle and left seating position

0 NotReqd

1 Reqd

ActvtOfActrThoraxAirbAtRowSecMidRi

Activate of Actuator Thorax Airbag at Row Second Middle Right

Activate head/thorax airbag at second row in between middle and right seating position

0 NotReqd

1 Reqd

ActvtOfActrThoraxAirbAtRowSecRi

Activate of Actuator Thorax Airbag at Row Second Right

Activate head/thorax airbag in second row at the right

0 NotReqd

1 Reqd

ActvtOfActrThoraxAirbAtRowThrdLe

Activate of Actuator Thorax Airbag at Row Third Left

Activate head/thorax airbag in third row at the left

0 NotReqd

1 Reqd

ActvtOfActrThoraxAirbAtRowThrdMidLe

Activate of Actuator Thorax Airbag at Row Third Middle Left

Activate head/thorax airbag at third row in between middle and left seating position

0 NotReqd

1 Reqd

ActvtOfActrThoraxAirbAtRowThrdMidRi

Activate of Actuator Thorax Airbag at Row Third Middle Right

Activate head/thorax airbag in third row in between middle and right seating position

0 NotReqd

1 Reqd

ActvtOfActrThoraxAirbAtRowThrdRi

Activate of Actuator Thorax Airbag at Row Third Right

Activate head/thorax airbag in third row at the right

0 NotReqd

1 Reqd

ActvtWipgAutFromHmi

Activate Wiping Automatic from HMI

Represents user's demand to activate / deactivate automatic front wiping. This demand is given by the Human Machine Interface (HMI) of the vehicle.

0 Off

1 On

AlrmSt

Alarm State

State of the alarm

0 Disarmed

1 PreArmed

2 Armed

3 Alrmd

AlrmVis

Visual Alarm

Command the visual alarm

0 Off

1 On

AxleFrntCoorrSt

Status of the Front Axle Coordinator

Status of the Front Axle Coordinator

0 Flt

1 NoFlt

AxleReCoorrSt

Status of the Rear Axle Coordinator

Status of the Rear Axle Coordinator

0 Flt

1 NoFlt

BackliteWinDiagcLock

Backlite Window Diagnostic Lock

Diagnostic request to manipulate an actuator component of the backlite window to unconditionally unlock, lock or safe at the latch

BackliteWinHmi

Backlite Window HMI

User request to release/unlock the Backlite of the vehicle.

0 Off

1 On

BackliteWinLockSt

Backlite Window Lock State

information about the current locking state of the backlite window

0 Imps

1 Unlckd

2 Lockd

3 Safe

4 Movg

BackliteWinLockgCmd

Backlite Window Locking Command

Locking command related to backlite window. This command locks or unlock the backlite window

0 Off

1 Unlck

2 Lock

3 Safe

BackliteWinLtchRels

Backlite Window Latch Release

Diagnostic request to the sensor component to release/unlock the latch of backlite window

BackliteWinPullAid

Backlite Window Pull Aid

This port provide the Pull Aid Command to assist the movement of the backlite window.

0 Off

1 Open

2 Cls

BackliteWinSt

Backlite Window Status

Information of the backlite window, indicates whether this window is opened or closed

0 Ukwn

1 Opend

2 Clsd

3 Ajar

4 Invld

BackliteWinSts

Backlite Window Status

Information of the backlite window, indicates whether this window is opened or closed

0 Ukwn

1 Opend

2 Clsd

3 Ajar

4 Invld

BeamHi

High Beam

This port provides command to turn on/off high beams

0 Off

1 On

BeamHiIndcn

High Beam Indication

This port provides Indication to the instrument cluster about the High beam on/off status

0 Off

1 On

BeamHiOut

High Beam Output

This port provides command to turn on/off high beams

0 Off

1 On

BeamLo

Low Beam

This port provides command to turn on/off low beams

0 Off

1 On

BeamLoIndcn

Low Beam Indication

This port provides Indication to the instrument cluster about the Low beam on/off status

0 Off

1 On

BeamLoOut

Low Beam Output

This port provides command to turn on/off low beams

0 Off

1 On

BltLockStAtDrvr

Belt Lock State at Driver

State of belt lock at driver seating position

0 Unlck

1 Lock

BltLockStAtPass

Belt Lock State at Passenger

State of belt lock at passenger seating position

0 Unlck

1 Lock

BltLockStAtRowFirstMid

Belt Lock State at Row First Middle

State of belt lock at seating position at middle of first row

0 Unlck

1 Lock

BltLockStAtRowSecLe

Belt Lock State at Row Second Left

State of belt lock at seating position at left of second row

0 Unlck

1 Lock

BltLockStAtRowSecMid

Belt Lock State at Row Second Middle

State of belt lock at seating position at middle of second row

0 Unlck

1 Lock

BltLockStAtRowSecRi

Belt Lock State at Row Second Right

State of belt lock at seating position at right of second row

0 Unlck

1 Lock

BltLockStAtRowThrdLe

Belt Lock State at Row Third Left

State of belt lock at seating position at left of third row

0 Unlck

1 Lock

BltLockStAtRowThrdMid

Belt Lock State at Row Third Middle

State of belt lock at seating position at middle of third row

0 Unlck

1 Lock

BltLockStAtRowThrdRi

Belt Lock State at Row Third Right

State of belt lock at seating position at right of third row

0 Unlck

1 Lock

BodyLvlCtrl

Body Level Control

Status of the body level control indicating the direction of the body movement.

0 Hld

1 Up

2 Dwn

BodyLvlMod

Body Level Mode

Current body level mode for display to the driver and provided to other systems.

0 Lo

1 Norm

2 Hi

BodyLvlModReq

Body Level Mode Request

Height level request to suspension system(s) by the driver.

0 Lo

1 Norm

2 Hi

BrkActrIntvg

Brake Actuator Intervening

Brake actuator is used to apply a pressure at at least one wheel.

0 Off

1 On

BrkActrMod

Brake Actuator Mode

Brake actuator action or status, with regards to parking brake functionality.

0 Reld

1 DurgRels

2 DurgApply

3 Appld

4 BrkgCtrlDyn

BrkActrOvrheatd

Brake Actuator Overheated

One flag indicating that temperature of at least one actuator component is high, e.g. valves overheated. If this flag is set the actuator is in a critical condition. The external function, e.g. Roll Stability Controller can decide whether to use the brake or not.

0 Norm

1 Ovrheatd

BrkActrSatn

Brake Actuator Saturation

Brake actuator saturation status. This is a not wheel individual but global information.

0 NoSatn

1 LimnSatnActv

BrkAssiReq

Brake Assist Request

Request from Vehicle Longitudinal Control (VLC) that the brake system should modify its brake assist mode for hazard situations.

0 NotReqd

1 Reqd

BrkLi

Brake Light

This port provides Brake lights activation command for lights adapters.

0 Off

1 On

BrkLiOnReqFromChassis

Brake Light on Request from Chassis

Request to illuminate brake lights.

0 NotReqd

1 Reqd

BrkModReq

Brake Mode Request

Indication whether the brake request is comfort or safety related.

0 Cmft

1 Sfty

BrkPedlFlgPsd

Brake Pedal Pressed

Information that the brake pedal is pressed.

0 NotPsd

1 Psd

BrkPedlOvrd

Brake Pedal Override

Information that any existing cruise control request is overridden by application of the brake pedal.

0 NotOvrdn

1 Ovrdn

BrkPedlPsd

Brake Pedal Pressed

Information that the brake pedal is pressed.

0 NotPsd

1 Psd

BrkPrevnCmftReqByAcc

Brake Prevention Comfort Request by ACC

Avoid brake interventions for comfort reasons requested by Adaptive Cruise Control (ACC) to be arbitrated by Vehicle Longitudinal Control (VLC).

0 NotReqd

1 Reqd

BrkPrevnCmftReqByVlc

Brake Prevention Comfort Request by Vehicle Longitudinal Control (VLC)

Request to avoid braking, e.g. for Adaptive Cruise Control and Vehicle Longitudinal Control. Request includes aspects from traffic point of view.

0 NotReqd

1 Reqd

BrkRdyReq

Brake Ready Request

Request from Vehicle Longitudinal Control (VLC) that the brake system is to be prepared for braking (e.g. air gap elimination).

0 NotReqd

1 Reqd

BrkTracCtrlIntvg

Brake Traction Control Intervening

Brake traction control intervention status. True if intervening at at least one wheel.

0 NoCtrl

1 InCtrl

BrkYawCtrlIntvgPerWhl

Brake Yaw Control Intervening per Wheel

Wheel with yaw stability brake control intervention (Vector of 4). Information for Roll Stability Control (RSC) and Suspension only. Wheel individual.

BtnReLeForSeatClima

Rear Left Button from HMI for Seat Climatisation

Rear Left Passenger Button Activation From Hmi (on, off) for Seat Climatisation

0 Off

1 On

BtnReRiForSeatClima

Rear Right Button from HMI for Seat Climatisation

Rear Right Passenger Button Activation From Hmi (on, off) for Seat Climatisation

0 Off

1 On

BtnSimple

Simple Button

Information if the button was pressed or not pressed.

0 NotPsd

1 Psd

BypSlipCtrlReqByRsc

Bypass Slip Control Request by RSC

Request from Roll Stability Control (RSC) only to inhibit internal Electronic Stability Control (ESC) slip control.

CarFindr

Car Finder

This information is related to the activation or deactivation of the car finder. This function is able to generate sounds or light to help the customer to find his vehicle

0 Off

1 On

ChdProtn

Door Child Protection

Diagnostic request to the actuator component for unconditional activation or deactivation of child lock of a door (disable opening of the door from inside)

ChgInfoOfBltLockSt

Change Information of Belt Lock State

Summery information: at least one state of the belt locks has changed

0 NoChgInfo

1 ChgInfo

ChimerFb

Chimer Feedback

Information feedback related to the command to turn On/Off the chimer in the cluster. The type of the chimer sequence is up to the driver implementation in the cluster.

0 Off

1 On

ConcHAndeDsConsold

Consolidated Value for Hydrogen concentration at downstream of anode

Hydrogen concentration at downstream of anode: Consolidated physical value, either a measured

value or a modeled value.

ConcHAndeDsElecBascFild

Electrical Basic Filtered Value of Hydrogen concentration at downstream of anode

Hydrogen concentration at downstream of anode: Basic filtered electrical raw sensor value.

ConcHAndeDsElecRaw

Electrical Raw Value of Hydrogen concentration at downstream of anode

Hydrogen concentration at downstream of anode: Electrical raw sensor value as provided by the ECU Abstraction.

ConcHAndeDsEstimd

Estimated Value of Hydrogen concentration at downstream of anode

Hydrogen concentration at downstream of anode: Modeled physical sensor value or standard sensor value.

ConcHAndeDsMeasd

Measured Value of Hydrogen concentration at downstream of anode

Hydrogen concentration at downstream of anode: Final filtered and offset corrected physical

sensor value.

ConcHAndeDsRaw

Raw Value of Hydrogen concentration at downstream of anode

Hydrogen concentration at downstream of anode: Physical raw sensor value.

CoolFltOfDrvrSeat

Cooling Fault from Actuator

Seat Cooling Fault From Actuator

0 NoFlt

1 Flt

CoolFltOfPassSeat

Cooling Fault from Actuator

Seat Cooling Fault From Actuator

0 NoFlt

1 Flt

CoolFltOfSeatReLe

Cooling Fault from Actuator

Seat Cooling Fault From Actuator

0 NoFlt

1 Flt

CoolFltOfSeatReRi

Cooling Fault from Actuator

Seat Cooling Fault From Actuator

0 NoFlt

1 Flt

CoolSeatFlt

Cooling Seat Fault from Actuator

Seat Cooling Fault From Actuator

0 NoFlt

1 Flt

CoolgCmdToActrOfSeatCoolg

Cooling Command to Actuator of Seat Cooling

Cooling command To Actuator Of a Seat

0 Off

1 On

CoorrStActAtAxleFrnt

Coordinator Status Actual at Axle Front

Status of the Front Axle Coordinator.

0 Flt

1 NoFlt

CoorrStActAtAxleRe

Coordinator Status Actual at Axle Rear

Status of the Rear Axle Coordinator.

0 Flt

1 NoFlt

CoorrStActAtDftlForTqTrf

Coordinator Status Actual at Differential for Torque Transfer

Status of the Transfer Case Coordinator.

0 Flt

1 NoFlt

CoorrStConsoldAtAxleFrnt

Coordinator Status Consolidated at Axle Front

Status of the Front Axle Coordinator.

0 Flt

1 NoFlt

CoorrStConsoldAtAxleRe

Coordinator Status Consolidated at Axle Rear

Status of the Rear Axle Coordinator.

0 Flt

1 NoFlt

CoorrStConsoldAtDftlForTqTrf

Coordinator Status Consolidated at Differential for Torque Transfer

Status of the Transfer Case Coordinator.

0 Flt

1 NoFlt

CornrMkr

Corner Marker

This port provides command to turn on the corner marker light

0 Off

1 On

CornrMkrLeOut

Corner Marker Left Output

This port provides command to turn on left corner marker light

0 Off

1 On

CornrMkrReq

Corner Marker Request

Request to activate corner markers

0 Off

1 Le

2 Ri

CornrMkrRiOut

Corner Marker Right Output

This port provides command to turn on right corner marker light

0 Off

1 On

Crash

Crash Status

This port provides the actual crash status pre-crash and post-crash

1 PreCrash

2 PostCrash

CrsCtrlActv

Cruise Control Active

Switch operated by driver to set Cruise Control stand-by mode to on.

0 Off

1 On

CrsCtrlAndAccDrvrOvrd

Cruise Control and Adaptive Cruise Control Driver Override

Adaptive Cruise Control or Cruise Control is overridden by driver.

0 NotOvrdn

1 Ovrdn

CrsCtrlAndAccSetTiGapDec

Cruise Control and Adaptive Cruise Control Set Time Gap Decrease

Status of decrease time gap switch of Adaptive Cruise Control (ACC). This switch is used to decrease the ACC time gap.

0 NotReqd

1 Reqd

CrsCtrlAndAccSetTiGapInc

Cruise Control and Adaptive Cruise Control Set Time Gap Increase

Status of increase time gap switch of Adaptive Cruise Control (ACC). This switch is used to increase the ACC time gap.

0 NotReqd

1 Reqd

CrsCtrlAndAccSwtStEngd

Cruise Control and Adaptive Cruise Control Switch Status Engaged

Status of the switch to engage, disengage or resume Adaptive Cruise Control or Cruise Control.

0 Set

1 Resu

2 Cncl

CrsCtrlAndAccSwtStsEngd

Cruise Control and Adaptive Cruise Control Switch Status Engaged

Status of the switch to engage, disengage or resume Adaptive Cruise Control or Cruise Control.

0 Set

1 Resu

2 Cncl

CrsCtrlCtrlActv

Cruise Control Control Active

Cruise Control is engaged and active. This information is used for display feedback for driver as well.

0 Off

1 On

2 Err

DamprCoeffEstimd

Damper Coefficient Estimated

Estimation of the actual damper coefficient provided by the damper system

DamprCoeffEstimd1

Damper Coefficient Estimated

Estimation of the actual damper coefficient provided by the damper system

DamprCtrlMod

Damper Control Mode

Damper tuning mode for display to the driver

0 SuspModStd

1 SuspModCmft

2 SuspModSpt

3 SuspModOffroad

DamprCtrlTunReq

Damper Control Tuning Request

Damper control tuning mode request by the driver.

0 SuspModStd

1 SuspModCmft

2 SuspModSpt

3 SuspModOffroad

DamprFEstimd

Damper Force Estimated

Estimation of the actual damper forces provided by the damper system.

DamprFEstimd1

Damper Force Estimated

Estimation of the actual damper forces provided by the damper system.

DamprRateCmpn

Damper Rate Compression

Current damper rate (compression) of active dampers.

DamprRateRbd

Damper Rate Rebound

Current damper rate (rebound) of active dampers.

DamprRateReqCmpn

Damper Rate Request Compression

Requested damper rate (compression) to be set by active damper system.

DamprRateReqRbd

Damper Rate Request Rebound

Requested damper rate (rebound) to be set by active damper system.

DamprSt

Damper Status

Status of the semi-active or switchable damper

0 Off

1 On

2 Err

DamprSts

Damper Status

Status of the semi-active or switchable damper

0 Off

1 On

2 Err

DateTi

Date Time

Represents the current date and the current time.

DefrstReqFrntFromHmi

Front Defrost Request from HMI

Port for Front Defrost Request From Hmi

0 Off

1 On

DefrstReqReFromHmi

Rear Defrost Request from HMI

Port for Rear Defrost Request From Hmi

0 Off

1 On

DftlYawStabyCtrlIntvg

Differential Yaw Stability Control Intervening

Indication whether the yaw stability control by drivetrain torque distribution is intervening or not.

0 NoCtrl

1 InCtrl

DiagcChdProtnOfDoorLockReLe

Rear Door Diagnostic Child Protection

Diagnostic request to the actuator component for unconditional activation or deactivation of child lock of a rear door (disable opening of the rear door from inside)

DiagcChdProtnOfDoorLockReRi

Rear Door Diagnostic Child Protection

Diagnostic request to the actuator component for unconditional activation or deactivation of child lock of a rear door (disable opening of the rear door from inside)

DiagcHtlMod

Diagnostic Hotel Mode

Diagnostic request to manipulate an actuator component of the hotel mode to unconditionally activate or deactivate this mode

DiagcLock

Door Diagnostic Lock

Diagnostic request to manipulate an actuator component of the door to unconditionally unlock, lock or safe at the latch

DiagcLockOfDoorLockReLe

Rear Door Diagnostic Lock

Diagnostic request to manipulate an actuator component of a rear door to unconditionally unlock, lock or safe at the latch

DiagcLockOfDoorLockReRi

Rear Door Diagnostic Lock

Diagnostic request to manipulate an actuator component of a rear door to unconditionally unlock, lock or safe at the latch

DiagcLockOfDrvrDoorLock

Front Door Diagnostic Lock

Diagnostic request to manipulate an actuator component of a front door to unconditionally unlock, lock or safe at the latch

DiagcLockOfLidRe

Diagnostic Lock of Lid Rear

Diagnostic request to manipulate an actuator component of the rear lid to unconditionally unlock, lock or safe at the latch

DiagcLockOfPassDoorLock

Front Door Diagnostic Lock

Diagnostic request to manipulate an actuator component of a front door to unconditionally unlock, lock or safe at the latch

DiagcPullAid

Door Diagnostic Pull Aid

Diagnostic request to manipulate an actuator component of the door to unconditionally activate or deactivate the pull aid of the door

DiagcPullAidOfDoorLockReLe

Rear Door Diagnostic Pull Aid

Diagnostic request to manipulate an actuator component of a rear door to unconditionally activate or deactivate the pull aid of the door

DiagcPullAidOfDoorLockReRi

Rear Door Diagnostic Pull Aid

Diagnostic request to manipulate an actuator component of a rear door to unconditionally activate or deactivate the pull aid of the door

DiagcPullAidOfDrvrDoorLock

Front Door Diagnostic Pull Aid

Diagnostic request to manipulate an actuator component of a front door to unconditionally activate or deactivate the pull aid of the door

DiagcPullAidOfPassDoorLock

Front Door Diagnostic Pull Aid

Diagnostic request to manipulate an actuator component of a front door to unconditionally activate or deactivate the pull aid of the door

DiagcReq

Diagnostic Request For A Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfAshtrayLiFrntCen

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfAshtrayLiFrntLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfAshtrayLiFrntRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfAshtrayLiGroup

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfAshtrayLiMidCen

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfAshtrayLiMidLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfAshtrayLiMidRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfAshtrayLiReCen

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfAshtrayLiReLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfAshtrayLiReRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfCbnLiFrntCen

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfCbnLiFrntLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfCbnLiFrntRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfCbnLiGroup

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfCbnLiMidCen

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfCbnLiMidLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfCbnLiMidRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfCbnLiReCen

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfCbnLiReLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfCbnLiReRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfCurbLiFrntLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfCurbLiFrntRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfCurbLiGroup

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfCurbLiMidLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfCurbLiMidRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfCurbLiReLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfCurbLiReRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfEngCmptmtLi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfExtrLiSwtIllmn

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfFootwellGroup

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfFootwellLiFrntCen

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfFootwellLiFrntLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfFootwellLiFrntRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfFootwellLiMidCen

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfFootwellLiMidLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfFootwellLiMidRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfFootwellLiReCen

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfFootwellLiReLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfFootwellLiReRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfGlvCmptmtLi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfIgnSwtIllmn

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfIntrLiGroup0

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfIntrLiGroup1

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfIntrLiGroup10

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfIntrLiGroup11

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfIntrLiGroup12

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfIntrLiGroup13

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfIntrLiGroup14

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfIntrLiGroup15

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfIntrLiGroup2

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfIntrLiGroup3

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfIntrLiGroup4

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfIntrLiGroup5

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfIntrLiGroup6

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfIntrLiGroup7

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfIntrLiGroup8

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfIntrLiGroup9

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForCigaretteLighterIllmnAtTrLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForCigaretteLighterIllmnAtTrRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForCigaretteLighterIllmnFrntCen

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForCigaretteLighterIllmnFrntLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForCigaretteLighterIllmnFrntRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForCigaretteLighterIllmnGroup

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForCigaretteLighterIllmnMidCen

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForCigaretteLighterIllmnMidLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForCigaretteLighterIllmnMidRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForCigaretteLighterIllmnReCen

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForCigaretteLighterIllmnReLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForCigaretteLighterIllmnReRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForDoorOpenerIllmnFrntLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForDoorOpenerIllmnFrntRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForDoorOpenerIllmnGroup

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForDoorOpenerIllmnMidLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForDoorOpenerIllmnMidRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForDoorOpenerIllmnReLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForDoorOpenerIllmnReRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForDoorSillIllmnFrntLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForDoorSillIllmnFrntRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForDoorSillIllmnGroup

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForDoorSillIllmnMidLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForDoorSillIllmnMidRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForDoorSillIllmnReLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForDoorSillIllmnReRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForReadingAtRowThrdCen

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForReadingAtRowThrdLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForReadingAtRowThrdRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForReadingFrntCen

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForReadingFrntLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForReadingFrntRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForReadingGroup

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForReadingReCen

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForReadingReLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForReadingReRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForSftyBltLockIllmnFrntCen

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForSftyBltLockIllmnFrntLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForSftyBltLockIllmnFrntRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForSftyBltLockIllmnGroup

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForSftyBltLockIllmnMidCen

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForSftyBltLockIllmnMidLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForSftyBltLockIllmnMidRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForSftyBltLockIllmnReCen

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForSftyBltLockIllmnReLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfLiForSftyBltLockIllmnReRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfSwtIllmnForHzrdWarn

Diagnostic Request of Hazard Warning Switch Illumination

Diagnostic Request for Hazard Warning Switch Illumination

DiagcReqOfTrCmptmtGroup

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfTrCmptmtLiCen

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfTrCmptmtLiLoLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfTrCmptmtLiLoRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfTrCmptmtLiUpLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfTrCmptmtLiUpRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfVanityLiFrntLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfVanityLiFrntRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfVanityLiGroup

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfVanityLiMidLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfVanityLiMidRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfVanityLiReLe

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DiagcReqOfVanityLiReRi

Diagnostic Request for Interior Light Source

Diagnostic request to manipulate a light actuator accordingly in order to unconditionally activate a light actuator with a certain brightness or release the light actuator. Initial value {0, Off}

DispBltLockAck

Display Belt Lock Acknowledge

Acknowledge from Human Machine Interface (HMI) to end the active warning / display request

0 NotReqd

1 Reqd

DispBltLockReq

Display Belt Lock Request

Request from seat belt reminder to Human Machine Interface (HMI) to signal a locked/non locked seat belt on seating position. The actual display content are to get from dedicated ports.

0 NotReqd

1 Reqd

DispBltLockStOfDrvr

Display Belt Lock State of Driver

State of the lock of belt at driver seating position to display in case of when the display belt lock requests.

0 Unlck

1 Lock

2 NotPrsnt

DispBltLockStOfPass

Display Belt Lock State of Passenger

State of the lock of belt at passenger seating position to display in case of when the display belt lock requests.

0 Unlck

1 Lock

2 NotPrsnt

DispBltLockStOfRowFirstMid

Display Belt Lock State of First Row Middle

State of the lock of belt at seating position at first row in the middle to display in case of when the display belt lock requests.

0 Unlck

1 Lock

2 NotPrsnt

DispBltLockStOfRowSecLe

Display Belt Lock State of Row Second Left

State of the lock of belt at seating position at second row in the left to display in case of when the display belt lock requests.

0 Unlck

1 Lock

2 NotPrsnt

DispBltLockStOfRowSecMid

Display Belt Lock State of Second Row Middle

State of the lock of belt at seating position at second row in the middle to display in case of when the display belt lock requests.

0 Unlck

1 Lock

2 NotPrsnt

DispBltLockStOfRowSecRi

Display Belt Lock State of Second Row Right

State of the lock of belt at seating position at second row in the right to display in case of when the display belt lock requests.

0 Unlck

1 Lock

2 NotPrsnt

DispBltLockStOfRowThrdLe

Display Belt Lock State of Third Row Left

State of the lock of belt at seating position at third row in the left to display in case of when the display belt lock requests.

0 Unlck

1 Lock

2 NotPrsnt

DispBltLockStOfRowThrdMid

Display Belt Lock State of Third Row Middle

State of the lock of belt at seating position at third row in the middle to display in case of when the display belt lock requests.

0 Unlck

1 Lock

2 NotPrsnt

DispBltLockStOfRowThrdRi

Display Belt Lock State of Third Row Right

State of the lock of belt at seating position at third row in the right to display in case of when the display belt lock requests.

0 Unlck

1 Lock

2 NotPrsnt

DispBucdStOfDrvr

Display Buckled State of Driver

State of buckled occupant displayed optionally for the driver seat position in case of seat belt reminder warning.

0 NotBucd

1 Bucd

2 NoOccpt

3 NotPrsnt

DispBucdStOfOccptAtRowFirstMid

Display Buckled State of Occupant at Row First Middle

State of buckled occupant displayed optionally for the seat position at first row in middle in case of seat belt reminder warning.

0 NotBucd

1 Bucd

2 NoOccpt

3 NotPrsnt

DispBucdStOfOccptAtRowSecLe

Display Buckled State of Occupant at Row Second Left

State of buckled occupant displayed optionally for the seat position at second row on left in case of seat belt reminder warning .

0 NotBucd

1 Bucd

2 NoOccpt

3 NotPrsnt

DispBucdStOfOccptAtRowSecMid

Display Buckled State of Occupant at Row Second Middle

State of buckled occupant displayed optionally for the seat position at second row in middle in case of seat belt reminder warning .

0 NotBucd

1 Bucd

2 NoOccpt

3 NotPrsnt

DispBucdStOfOccptAtRowSecRi

Display Buckled State of Occupant at Row Second Right

State of buckled occupant displayed optionally for the seat position at second row on right in case of seat belt reminder warning.

0 NotBucd

1 Bucd

2 NoOccpt

3 NotPrsnt

DispBucdStOfOccptAtRowThrdLe

Display Buckled State of Occupant at Row Third Left

State of buckled occupant displayed optionally for the seat position at third row on left in case of seat belt reminder warning.

0 NotBucd

1 Bucd

2 NoOccpt

3 NotPrsnt

DispBucdStOfOccptAtRowThrdMid

Display Buckled State of Occupant at Row Third Middle

State of buckled occupant displayed optionally for the seat position at third row in middle in case of seat belt reminder warning.

0 NotBucd

1 Bucd

2 NoOccpt

3 NotPrsnt

DispBucdStOfOccptAtRowThrdRi

Display Buckled State of Occupant at Row Third Right

State of buckled occupant displayed optionally for the seat position at third row on right in case of seat belt reminder warning.

0 NotBucd

1 Bucd

2 NoOccpt

3 NotPrsnt

DispBucdStOfPass

Display Buckled State of Passenger

State of buckled occupant displayed optionally for the passenger seat position in case of seat belt reminder warning.

0 NotBucd

1 Bucd

2 NoOccpt

3 NotPrsnt

DispRainSnsrActv

Display Rain Sensor Active

Informs driver, if rain sensor is currently active.

0 Off

1 On

DoorChdCmd

Door Child Command

Command to activate or deactivate the child protection related to a door.

0 Off

1 Actvt

2 Deactvt

DoorChdCmdOfDoorLockReLe

Rear Door Child Command

Command to activate or deactivate the child protection related to a rear door.

0 Off

1 Actvt

2 Deactvt

DoorChdCmdOfDoorLockReRi

Rear Door Child Command

Command to activate or deactivate the child protection related to a rear door.

0 Off

1 Actvt

2 Deactvt

DoorChdSt

Door Child Status

Status of the child protection related to a door.

0 Off

1 On

DoorChdStOfDoorLockReLe

Rear Door Child State

State of the child protection related to a rear door.

0 Off

1 On

DoorChdStOfDoorLockReRi

Rear Door Child State

State of the child protection related to a rear door.

0 Off

1 On

DoorHndl

Door Handle

Information related to the door handle (door handle activated or not)

0 NotTouchd

1 Touchd

2 Invld

DoorHndlSen

Door Handle Sensor

Information related to the door handle sensor (door handle sensor touched or not)

0 NotTouchd

1 Touchd

2 Invld

DoorKeyPadOfLidRe

Rear Lid Door Keypad

Request to activate central locking master on the rear lid from door key pad

DoorKeyPadReLe

Rear Left Door Keypad

Request to activate central locking master from the rear left door key pad

DoorKeyPadReLeOfLidRe

Rear Left Door Keypad Rear Lid

Request to activate central locking master on the rear lid from the rear left door key pad

DoorKeyPadReRi

Rear Right Door Keypad

Request to activate central locking master from the rear right door key pad

DoorKeyPadReRiOfLidRe

Rear Right Door Keypad Rear Lid

Request to activate central locking master on the rear lid from the rear right door key pad

DoorSt

Door Status

Information of the door, indicates whether this door is opened or closed

0 Ukwn

1 Opend

2 Clsd

3 Ajar

4 Invld

DoorStOfDoorLockReLe

Rear Door Status

Information of a rear door, indicates whether this door is opened or closed

0 Ukwn

1 Opend

2 Clsd

3 Ajar

4 Invld

DoorStOfDoorLockReRi

Rear Door Status

Information of a rear door, indicates whether this door is opened or closed

0 Ukwn

1 Opend

2 Clsd

3 Ajar

4 Invld

DoorStOfDrvrDoorLock

Front Door Status

Information of the front door, indicates whether this door is opened or closed

0 Ukwn

1 Opend

2 Clsd

3 Ajar

4 Invld

DoorStOfPassDoorLock

Front Door Status

Information of the front door, indicates whether this door is opened or closed

0 Ukwn

1 Opend

2 Clsd

3 Ajar

4 Invld

DoorSts

Door Status

Information of the door, indicates whether this door is opened or closed

0 Ukwn

1 Opend

2 Clsd

3 Ajar

4 Invld

DoorStsOfDoorLockReLe

Rear Door Status

Information of a rear door, indicates whether this door is opened or closed

0 Ukwn

1 Opend

2 Clsd

3 Ajar

4 Invld

DoorStsOfDoorLockReRi

Rear Door Status

Information of a rear door, indicates whether this door is opened or closed

0 Ukwn

1 Opend

2 Clsd

3 Ajar

4 Invld

DoorStsOfDrvrDoorLock

Front Door Status

Information of the front door, indicates whether this door is opened or closed

0 Ukwn

1 Opend

2 Clsd

3 Ajar

4 Invld

DoorStsOfPassDoorLock

Front Door Status

Information of the front door, indicates whether this door is opened or closed

0 Ukwn

1 Opend

2 Clsd

3 Ajar

4 Invld

DrvFlgGearShiftDwnReq

Gear Shift Down Request by Driver

Gear shift down request by driver

0 NotPsd

1 Psd

DrvFlgGearShiftUpReq

Gear Shift Up Request by Driver

Gear shift up request by driver

0 NotPsd

1 Psd

DrvgSide

Driving Side

Information related to the position of the steering wheel in the vehicle (right or left)

0 Le

1 Ri

DrvrBtnForSeatClima

Driver Button from HMI for Seat Climatisation

Driver Button Activation From Hmi (on, off) for Seat Climatisation

0 Off

1 On

DrvrDoorKeyPad

Driver Door Keypad

Request to activate central locking master from the driver door key pad

DrvrDoorKeyPadOfLidRe

Driver Door Keypad Rear Lid

Request to activate central locking master on the rear lid from the driver door key pad

DrvrProf

Driver Profile

Status of current selected personalization profile from profile manager. It is a common profile selectable from transponder, remote key, keyless access, Human Machine Interface (HMI),...

0 NoProf

1 Prof1

2 Prof2

3 Prof3

4 Prof4

5 Prof5

6 Prof6

7 Prof7

8 Prof8

9 Prof9

10 Prof10

11 Prof11

12 Prof12

13 Prof13

14 Prof14

15 Prof15

DrvrStgDispForSeatClima

Driver Stage Display for Seat Climatisation to HMI

Feedback to Hmi of Driver Stage requested

0 NoClima

1 Cold1

2 Cold2

3 Cold3

4 Heat1

5 Heat2

6 Heat3

DrvrStgForSeatClima

Driver Stage Request for Seat Climatisation

Driver Stage Request (no climatisation, heating level, cooling level)

0 NoClima

1 Cold1

2 Cold2

3 Cold3

4 Heat1

5 Heat2

6 Heat3

DtOpend

Drivetrain Opened

Indicates whether the drive train is open due to driver input. Transitional states between fully open and fully closed drivetrain shall be indicated as open in this signal.

0 Rst

1 Set

DtTqDistbnStIndcn

Drivetrain Torque Distribution Status Indication

Indication of Drivetrain torque distribution functional status.

0 Off

1 On

2 Err

DtTqDistbnStsIndcn

Drivetrain Torque Distribution Status Indication

Indication of Drivetrain torque distribution functional status.

0 Off

1 On

2 Err

DtdRatTqDistbnReq

Requested Drivetrain Torque Distribution

The Drivetrain Torque Distribution strategy in chassis requests a distribution of the total powertrain torque at wheels, not a modification to that total torque. Therefore the distribution is requested as a percentage value for each wheel.

EgyMngt

Energy Management

Information used to optimize the energy available in the vehicle. This port is used to communicate a potential need of optimization of the energy available in the vehicle through functions. Functions will adapt their behaviours in adequacy with the optimization needed and with their own constraints.

0 NoFctPsbl

1 SftyFctOnly

2 HbrntLvl1

3 HbrntLvl2

4 HbrntLvl3

5 LimnLvl1

6 LimnLvl2

7 LimnLvl3

8 LimnLvl4

9 FullFct

10 CnseEgy

EgyMngtSt

State of Energy Management

This signal reflects the load dump stages in case of improper battery/generator balance. The handling of over- or under-voltage is not covered within this signal.

0 NoFctPsbl

1 SftyFctOnly

2 HbrntLvl1

3 HbrntLvl2

4 HbrntLvl3

5 LimnLvl1

6 LimnLvl2

7 LimnLvl3

8 LimnLvl4

9 FullFct

10 CnseEgy

EmgyBrk

Emergency Brake

This port provides request to turn on hazard warning due to heavy deceleration

0 Off

1 On

EmgyLockg

Emergency Locking

User request for emergency locking in case of danger.

0 Idle

1 Unlck

2 Lock

EngHoodSt

Engine Hood Status

Indication about engine hood (or bonnet) status.

0 Opend

1 Clsd

EngHoodSts

Engine Hood Status

Indication about engine hood (or bonnet) status.

0 Opend

1 Clsd

EngId

Engine Identifier

Identifier of the engine, for validation by Immobilizer.

EngIdReq

Engine Identifier Request

Request for engine identifier from Immobilizer.

EngRunngDirSt

Engine: Engine Running Direction State

Engine running direction state.

0 EngRunngDirUndefd

1 EngRunngDirPos

2 EngRunngDirNeg

3 EngRunngDirInvldErr

EngStrtRem

Remote Engine Start

Information to start the engine from a remote control

0 NoReq

1 EngStrtReq

EngTqCrksftMaxEngNCur

Engine: Maximum Torque at Crankshaft at Current Engine Speed

Maximum possible torque at crankshaft at current speed with maximum possible air mass at current ambient pressure and air temperature, including static power limitation of the engine.

EngTracCtrlIntvg

Engine Traction Control Intervening

Engine traction control is intervening (TRUE) when a torque reduction at the wheels is requested. Traction control is not intervening (indicated by FALSE) when a torque reduction at the wheels is not requested.

0 NoCtrl

1 InCtrl

EpbActrFltSt

EPB Actuator Fault Status

Failure status of the parking brake actuators

0 NoFlt

1 Flt

EpbActrFltSts

EPB Actuator Fault Status

Failure status of the parking brake actuators

0 NoFlt

1 Flt

EpbActrMod

EPB Actuator Mode

Indication of the action executed by the parking brake actuator or its status.

0 Reld

1 DurgRels

2 DurgApply

3 Appld

4 BrkgCtrlDyn

EpbActvn

EPB Activation

Activation or deactivation of the Electric Parking Brake by the driver.

0 Off

1 On

2 Err

EpbBtnCtrlSt

EPB Button Control Status

Status of Electric Parking Brake (EPB) control button

0 NoReq

1 ApplyReq

2 RelsReq

3 Actvd

4 Ukwn

EpbBtnCtrlSts

EPB Button Control Status

Status of Electric Parking Brake (EPB) control button

0 NoReq

1 ApplyReq

2 RelsReq

3 Actvd

4 Ukwn

EpbDrvrActvnIndcn

EPB Driver Activation Indication

Indication to the cockpit (HMI) that the driver has applied/released the parking brake.

0 Off

1 On

2 Err

EscCtrlIndcn

ESC Control Indication

Electronic Stability Control (ESC) controller is intervening.

0 Off

1 On

2 Err

EscFlgNoFuCutOff

Request "No Fuel Cut Off" by Electronic Stability Control (ESC)

Suppress engine fuel cut off - 0: no suppression of fuel cut off - 1: suppression of fuel cut off

0 NotReqd

1 Reqd

EscReqPasMod

ESC Request Passive Mode

Request to switch the Electronic Stability Control (ESC) system to a passive mode.

0 Off

1 On

2 Err

EscSt

Electronic Stability Control (ESC) Status

Status of activation/ deactivation of Electronic Stability Control (ESC)

0 Inin

1 Ok

2 TmpErr

3 PrmntErr

4 UsrOff

EscStIndcn

ESC Status Indication

Electronic Stability Control (ESC) is turned on.

0 Off

1 On

2 Err

EscStShiftPrevnStaby

Electronic Stability Control (ESC): State of Shift Prevention for Stability Reasons

Avoid change of gear for stability reasons.

0 NoReq

1 InhbShiftUp

2 InhbShiftDwn

3 InhbShiftAll

EscSts

Electronic Stability Control (ESC) Status

Status of activation/ deactivation of Electronic Stability Control (ESC)

0 Inin

1 Ok

2 TmpErr

3 PrmntErr

4 UsrOff

EscStsIndcn

ESC Status Indication

Electronic Stability Control (ESC) is turned on.

0 Off

1 On

2 Err

EscVWhlInd

Electronic Stability Control (ESC): Vector of Individual Speed of Wheels

Vector of 4 scalars in the order front left, front right, rear left, rear right. These scalars are the product of the individual angular velocities with the nominal (or static) rolling radius. The nominal (or static) rolling radius is representative of each vehicle, and is a value such that the standard circumferential wheel speed is very close to the vehicle longitudinal speed of the vehicle. If signal is not provided (optional) the radius must be available as a parameter

FanSt

Fan State

Activation state of climatisation or ventilation

0 Off

1 On

2 Err

FbAlrmAcoust

Acoustical Feedback Alarm

Acoustical Feedback from the alarm device

0 Off

1 On

FbPanicAlrmAcoust

Acoustical Feedback Panic Alarm

Acoustical Feedback from the panic alarm device

0 Off

1 On

FbPanicAlrmVis

Visual Feedback Panic Alarm

Visual Feedback from the panic alarm device

0 Off

1 On

FlashBeam

Flash Beam

This port provides Flash beam command

0 Off

1 On

FlashBeamIndcn

Flash Beam Indication

This port provides Indication to the instrument cluster about the Flash beam on/off status

0 Off

1 On

FlashBeamOut

Flash Beam Output

This port provides Flash beam command

0 Off

1 On

FltOfSeatClima

Seat Climatisation Fault From Actuator

Seat Climatisation Fault From Actuator

0 NoFlt

1 Flt

FobId

Fob Identifier

Identifier of the Fob, for validation by Immobilizer.

FobIdReq

Fob Identifier Request

Request for Fob identifier from Immobilizer.

FogFrnt

Front Fog Light

This port provides command to turn on/off front fog lights

0 Off

1 On

FogFrntOut

Front Fog Light Output

This port provides command to turn on/off front fog lights

0 Off

1 On

FogIndcnFrnt

Front Fog Light Indication

This port provides Indication to the instrument cluster about the Front fog lights on/off status

0 Off

1 On

FogIndcnRe

Rear Fog Light Indication

This port provides Indication to the instrument cluster about the Rear fog lights on/off status

0 Off

1 On

FogRe

Rear Fog Light

This port provides command to turn on/off rear fog lights

0 Off

1 On

FogReOut

Rear Fog Light Output

This port provides command to turn on/off rear fog lights

0 Off

1 On

GbxCtrsftActv

Gearbox: Countershaft Active

Indicates whether the gear is in low range mode, e.g. for sport utility vehicles (SUV) or Offroad-vehicles with countershaft gearboxes (high range / low range). - 0: countershaft inactive (standard condition) - 1: countershaft active

0 Rst

1 Set

GearParkEngd

Gear Park Engaged

Status of gearbox on engaged parking lock (P-drive) of the Automatic Transmission (AT). 0 : not engaged 1 : engaged

0 Rst

1 Set

GearParkReq

Gear Park Request

Parking lock request from Stand Still Manager to automatic transmission to set parking position.

0 NotReqd

1 Reqd

GearShiftDwnReqFromDrvr

Gear shift down request by driver

Gear shift down request by driver

0 NotPsd

1 Psd

GearShiftPrevnCmftReqByAcc

Gear Shift Prevention Comfort Request by ACC

Avoid change of gear for comfort reasons requested by Adaptive Cruise Control (ACC) to be arbitrated by Vehicle Longitudinal Control (VLC).

0 NoReq

1 InhbShiftUp

2 InhbShiftDwn

3 InhbShiftAll

GearShiftPrevnCmftReqByVlc

Gear Shift Prevention Comfort Request by Vehicle Longitudinal Control (VLC)

Request to avoid change of gear for comfort reasons: Request to avoid shifting request includes aspects from traffic point of view. Final decision remains in the actuator control. Acceleration request tolerance band has higher priority than the gear shift prevention comfort.

0 NoReq

1 InhbShiftUp

2 InhbShiftDwn

3 InhbShiftAll

GearShiftPrevnStaby

Gear Shift Prevention Stability

Command to avoid change of gear for stability reasons.

0 NoReq

1 InhbShiftUp

2 InhbShiftDwn

3 InhbShiftAll

GearShiftUpReqFromDrvr

Gear shift up request by driver

Gear shift up request by driver

0 NotPsd

1 Psd

GlvBoxHmi

Glove Box HMI

User request to lock / unlock the glovebox

0 Off

1 On

GlvBoxLockSt

Glove Box Lock State

Locking state of the glove box

0 Imps

1 Unlckd

2 Lockd

3 Safe

4 Movg

GlvBoxLockgCmd

Glove Box Locking Command

Command to lock the glove box

0 Off

1 Unlck

2 Lock

3 Safe

GlvBoxLtchRels

Glove Box Latch Release

Diagnostic request to the sensor component to release/unlock the latch of the glovebox

GlvBoxLtchRelsTog

Glove Box Latch Release Toggle

Diagnostic request to the sensor component to request a "Toggle-Function" of the latch of the glovebox

GlvBoxSt

Glove Box State

Information related to the glove box, it indicates whether the glove box is opened or closed

0 Opend

1 Clsd

HdlampWshngFromHmi

Head Lamp Washing from HMI

Carries a user request to activate the washing of headlamps. This demand is provided by the Human Machine Interface (HMI) of the vehicle

0 Off

1 On

HeatFltOfDrvrSeat

Heating Fault from Actuator

Seat Heating Fault From Actuator

0 NoFlt

1 Flt

HeatFltOfPassSeat

Heating Fault from Actuator

Seat Heating Fault From Actuator

0 NoFlt

1 Flt

HeatFltOfSeatReLe

Heating Fault from Actuator

Seat Heating Fault From Actuator

0 NoFlt

1 Flt

HeatFltOfSeatReRi

Heating Fault from Actuator

Seat Heating Fault From Actuator

0 NoFlt

1 Flt

HeatSeatFlt

Heating Seat Fault from Actuator

Seat Heating Fault From Actuator

0 NoFlt

1 Flt

HeatgCmdToActrOfSeatHeatg

Heating Command to Actuator of Seat Heating

Heating command To Actuator Of a Seat

0 Off

1 On

HldOnDmdSt

Hold on Demand Status

Failure status of the Hold On Demand function

0 Avl

1 NotAvlAndVehMovg

2 NotAvlAndFailr

HldOnDmdSts

Hold on Demand Status

Failure status of the Hold On Demand function

0 Avl

1 NotAvlAndVehMovg

2 NotAvlAndFailr

HndbrkSwt

Handbrake Switch

Indication that the handbrake switch is applied.

0 Off

1 On

HomeCmngAndHomeLvngOut

Coming Home Leaving Home Output

This port provides command to activate coming home/leaving home lights

0 Off

1 On

HomeCmngAndHomeLvngReq

Coming Home Leaving Home

Request to start coming home/leaving home.

0 Off

1 HomeCmng

2 HomeLvng

HoopRollCmd

Roll Hoop Command

Command for roll hoop

0 Off

1 On

HoopRollSt

Roll Hoop Status

Status of roll hoop actuator

0 NoFlt

1 Flt

HoopRollSts

Roll Hoop Status

Status of roll hoop actuator

0 NoFlt

1 Flt

HornActvn

Horn Activation Command

Command to activate or deactivate the horn actuator

0 Off

1 On

HornDispDfct

Horn Defect Display

Information on defect related to the horn control

0 Off

1 On

HornReqFromHmi

Horn Request from HMI

Request for horn. This request comes from the HMI

0 Off

1 On

HornSt

Horn Status

Fault state of the horn actuator

0 NoFlt

1 Flt

HornSts

Horn Status

Fault state of the horn actuator

0 NoFlt

1 Flt

HtlMod

Hotel Mode

Request to activate or deactivate the hotel mode. Hotel mode is a subset of the customer mode, example: minimum access to the vehicle without any access to the glovebox.

0 Off

1 On

HtlModSt

Hotel Mode Status

Information of the activation/deactivation of the hotel mode

0 Off

1 On

HtlModSts

Hotel Mode Status

Information of the activation/deactivation of the hotel mode

0 Off

1 On

HumAirFilDsConsold

Consolidated Value for Air humidity downstream air filter

Air humidity downstream air filter: Consolidated physical value, either a measured

value or a modeled value.

-INF...+INF

HumAirFilDsElecBascFild

Electrical Basic Filtered Value of Air humidity downstream air filter

Air humidity downstream air filter: Basic filtered electrical raw sensor value.

HumAirFilDsElecRaw

Electrical Raw Value of Air humidity downstream air filter

Air humidity downstream air filter: Electrical raw sensor value as provided by the ECU Abstraction.

HumAirFilDsEstimd

Estimated Value of Air humidity downstream air filter

Air humidity downstream air filter: Modeled physical sensor value or standard sensor value.

-INF...+INF

HumAirFilDsMeasd

Measured Value of Air humidity downstream air filter

Air humidity downstream air filter: Final filtered and offset corrected physical

sensor value.

-INF...+INF

HumAirFilDsRaw

Raw Value of Air humidity downstream air filter

Air humidity downstream air filter: Physical raw sensor value.

-INF...+INF

HumGasAndeUsConsold

Consolidated Value for Gas humidity at upstream of anode

Gas humidity at upstream of anode: Consolidated physical value, either a measured

value or a modeled value.

-INF...+INF

HumGasAndeUsElecBascFild

Electrical Basic Filtered Value of Gas humidity at upstream of anode

Gas humidity at upstream of anode: Basic filtered electrical raw sensor value.

HumGasAndeUsElecRaw

Electrical Raw Value of Gas humidity at upstream of anode

Gas humidity at upstream of anode: Electrical raw sensor value as provided by the ECU Abstraction.

HumGasAndeUsEstimd

Estimated Value of Gas humidity at upstream of anode

Gas humidity at upstream of anode: Modeled physical sensor value or standard sensor value.

-INF...+INF

HumGasAndeUsMeasd

Measured Value of Gas humidity at upstream of anode

Gas humidity at upstream of anode: Final filtered and offset corrected physical

sensor value.

-INF...+INF

HumGasAndeUsRaw

Raw Value of Gas humidity at upstream of anode

Gas humidity at upstream of anode: Physical raw sensor value.

-INF...+INF

HumGasBypHumrCtdeUsConsold

Consolidated Value for Gas humidity at bypass of humidifer on cathode side

Gas humidity at bypass of humidifer on cathode side: Consolidated physical value, either a measured

value or a modeled value.

-INF...+INF

HumGasBypHumrCtdeUsElecBascFild

Electrical Basic Filtered Value of Gas humidity at bypass of humidifer on cathode side

Gas humidity at bypass of humidifer on cathode side: Basic filtered electrical raw sensor value.

HumGasBypHumrCtdeUsElecRaw

Electrical Raw Value of Gas humidity at bypass of humidifer on cathode side

Gas humidity at bypass of humidifer on cathode side: Electrical raw sensor value as provided by the ECU Abstraction.

HumGasBypHumrCtdeUsEstimd

Estimated Value of Gas humidity at bypass of humidifer on cathode side

Gas humidity at bypass of humidifer on cathode side: Modeled physical sensor value or standard sensor value.

-INF...+INF

HumGasBypHumrCtdeUsMeasd

Measured Value of Gas humidity at bypass of humidifer on cathode side

Gas humidity at bypass of humidifer on cathode side: Final filtered and offset corrected physical

sensor value.

-INF...+INF

HumGasBypHumrCtdeUsRaw

Raw Value of Gas humidity at bypass of humidifer on cathode side

Gas humidity at bypass of humidifer on cathode side: Physical raw sensor value.

-INF...+INF

HzrdWarn

Hazard Warning

This port provides Indication to Instrument cluster and other body functionalities of Hazard lamps activation status. Use case: illumination of hazard switch is often used for functional indication too (see Internal Lights)

0 Off

1 On

IFbVlvBypCtdeConsold

Consolidated Value for Current feedback of cathode bypass valve

Current feedback of cathode bypass valve: Consolidated physical value, either a measured

value or a modeled value.

IFbVlvBypCtdeElecBascFild

Electrical Basic Filtered Value of Current feedback of cathode bypass valve

Current feedback of cathode bypass valve: Basic filtered electrical raw sensor value.

IFbVlvBypCtdeElecRaw

Electrical Raw Value of Current feedback of cathode bypass valve

Current feedback of cathode bypass valve: Electrical raw sensor value as provided by the ECU Abstraction.

IFbVlvBypCtdeEstimd

Estimated Value of Current feedback of cathode bypass valve

Current feedback of cathode bypass valve: Modeled physical sensor value or standard sensor value.

IFbVlvBypCtdeMeasd

Measured Value of Current feedback of cathode bypass valve

Current feedback of cathode bypass valve: Final filtered and offset corrected physical

sensor value.

IFbVlvBypCtdeRaw

Raw Value of Current feedback of cathode bypass valve

Current feedback of cathode bypass valve: Physical raw sensor value.

IFbVlvBypHumrCtdeConsold

Consolidated Value for Current feedback of cathode humidifier bypass valve

Current feedback of cathode humidifier bypass valve: Consolidated physical value, either a measured

value or a modeled value.

IFbVlvBypHumrCtdeElecBascFild

Electrical Basic Filtered Value of Current feedback of cathode humidifier bypass valve

Current feedback of cathode humidifier bypass valve: Basic filtered electrical raw sensor value.

IFbVlvBypHumrCtdeElecRaw

Electrical Raw Value of Current feedback of cathode humidifier bypass valve

Current feedback of cathode humidifier bypass valve: Electrical raw sensor value as provided by the ECU Abstraction.

IFbVlvBypHumrCtdeEstimd

Estimated Value of Current feedback of cathode humidifier bypass valve

Current feedback of cathode humidifier bypass valve: Modeled physical sensor value or standard sensor value.

IFbVlvBypHumrCtdeMeasd

Measured Value of Current feedback of cathode humidifier bypass valve

Current feedback of cathode humidifier bypass valve: Final filtered and offset corrected physical

sensor value.

IFbVlvBypHumrCtdeRaw

Raw Value of Current feedback of cathode humidifier bypass valve

Current feedback of cathode humidifier bypass valve: Physical raw sensor value.

IFbVlvBypTrbConsold

Consolidated Value for Current feedback of turbine bypass valve

Current feedback of turbine bypass valve: Consolidated physical value, either a measured

value or a modeled value.

IFbVlvBypTrbElecBascFild

Electrical Basic Filtered Value of Current feedback of turbine bypass valve

Current feedback of turbine bypass valve: Basic filtered electrical raw sensor value.

IFbVlvBypTrbElecRaw

Electrical Raw Value of Current feedback of turbine bypass valve

Current feedback of turbine bypass valve: Electrical raw sensor value as provided by the ECU Abstraction.

IFbVlvBypTrbEstimd

Estimated Value of Current feedback of turbine bypass valve

Current feedback of turbine bypass valve: Modeled physical sensor value or standard sensor value.

IFbVlvBypTrbMeasd

Measured Value of Current feedback of turbine bypass valve

Current feedback of turbine bypass valve: Final filtered and offset corrected physical

sensor value.

IFbVlvBypTrbRaw

Raw Value of Current feedback of turbine bypass valve

Current feedback of turbine bypass valve: Physical raw sensor value.

IFbVlvHPurgDrnConsold

Consolidated Value for Current feedback of combined purge and drain valve

Current feedback of combined purge and drain valve: Consolidated physical value, either a measured

value or a modeled value.

IFbVlvHPurgDrnElecBascFild

Electrical Basic Filtered Value of Current feedback of combined purge and drain valve

Current feedback of combined purge and drain valve: Basic filtered electrical raw sensor value.

IFbVlvHPurgDrnElecRaw

Electrical Raw Value of Current feedback of combined purge and drain valve

Current feedback of combined purge and drain valve: Electrical raw sensor value as provided by the ECU Abstraction.

IFbVlvHPurgDrnEstimd

Estimated Value of Current feedback of combined purge and drain valve

Current feedback of combined purge and drain valve: Modeled physical sensor value or standard sensor value.

IFbVlvHPurgDrnMeasd

Measured Value of Current feedback of combined purge and drain valve

Current feedback of combined purge and drain valve: Final filtered and offset corrected physical

sensor value.

IFbVlvHPurgDrnRaw

Raw Value of Current feedback of combined purge and drain valve

Current feedback of combined purge and drain valve: Physical raw sensor value.

IFbVlvShtOffCtdeDsConsold

Consolidated Value for Current feedback of shutoff valve downstream cathode

Current feedback of shutoff valve downstream cathode: Consolidated physical value, either a measured

value or a modeled value.

IFbVlvShtOffCtdeDsElecBascFild

Electrical Basic Filtered Value of Current feedback of shutoff valve downstream cathode

Current feedback of shutoff valve downstream cathode: Basic filtered electrical raw sensor value.

IFbVlvShtOffCtdeDsElecRaw

Electrical Raw Value of Current feedback of shutoff valve downstream cathode

Current feedback of shutoff valve downstream cathode: Electrical raw sensor value as provided by the ECU Abstraction.

IFbVlvShtOffCtdeDsEstimd

Estimated Value of Current feedback of shutoff valve downstream cathode

Current feedback of shutoff valve downstream cathode: Modeled physical sensor value or standard sensor value.

IFbVlvShtOffCtdeDsMeasd

Measured Value of Current feedback of shutoff valve downstream cathode

Current feedback of shutoff valve downstream cathode: Final filtered and offset corrected physical

sensor value.

IFbVlvShtOffCtdeDsRaw

Raw Value of Current feedback of shutoff valve downstream cathode

Current feedback of shutoff valve downstream cathode: Physical raw sensor value.

IFbVlvShtOffCtdeUsConsold

Consolidated Value for Current feedback of shutoff valve upstream cathode

Current feedback of shutoff valve upstream cathode: Consolidated physical value, either a measured

value or a modeled value.

IFbVlvShtOffCtdeUsElecBascFild

Electrical Basic Filtered Value of Current feedback of shutoff valve upstream cathode

Current feedback of shutoff valve upstream cathode: Basic filtered electrical raw sensor value.

IFbVlvShtOffCtdeUsElecRaw

Electrical Raw Value of Current feedback of shutoff valve upstream cathode

Current feedback of shutoff valve upstream cathode: Electrical raw sensor value as provided by the ECU Abstraction.

IFbVlvShtOffCtdeUsEstimd

Estimated Value of Current feedback of shutoff valve upstream cathode

Current feedback of shutoff valve upstream cathode: Modeled physical sensor value or standard sensor value.

IFbVlvShtOffCtdeUsMeasd

Measured Value of Current feedback of shutoff valve upstream cathode

Current feedback of shutoff valve upstream cathode: Final filtered and offset corrected physical

sensor value.

IFbVlvShtOffCtdeUsRaw

Raw Value of Current feedback of shutoff valve upstream cathode

Current feedback of shutoff valve upstream cathode: Physical raw sensor value.

IFbVlvThrExhConsold

Consolidated Value for Current feedback of exhaust throttle valve

Current feedback of exhaust throttle valve: Consolidated physical value, either a measured

value or a modeled value.

IFbVlvThrExhElecBascFild

Electrical Basic Filtered Value of Current feedback of exhaust throttle valve

Current feedback of exhaust throttle valve: Basic filtered electrical raw sensor value.

IFbVlvThrExhElecRaw

Electrical Raw Value of Current feedback of exhaust throttle valve

Current feedback of exhaust throttle valve: Electrical raw sensor value as provided by the ECU Abstraction.

IFbVlvThrExhEstimd

Estimated Value of Current feedback of exhaust throttle valve

Current feedback of exhaust throttle valve: Modeled physical sensor value or standard sensor value.

IFbVlvThrExhMeasd

Measured Value of Current feedback of exhaust throttle valve

Current feedback of exhaust throttle valve: Final filtered and offset corrected physical

sensor value.

IFbVlvThrExhRaw

Raw Value of Current feedback of exhaust throttle valve

Current feedback of exhaust throttle valve: Physical raw sensor value.

ImobAlrmReq

Immobilizer Alarm Request

Request to activate/deactivate the acoustic indication

0 Off

1 On

ImobSt

Immobilizer Status

Status of the Immobilizer

0 FobBattLo

1 NoFob

2 FobNotProgd

3 Authn

4 NoAuthn

5 LrngSt

6 Err

ImobSts

Immobilizer Status

Status of the Immobilizer

0 FobBattLo

1 NoFob

2 FobNotProgd

3 Authn

4 NoAuthn

5 LrngSts

6 Err

ImobnWirels

Immobilization Request from Wireless

Signal to immobilize the vehicle from a wireless terminal

0 NotAvl

1 On

2 Off

3 Err

ImpctLocnEstimdOfCrashAtFrnt

Impact Location Estimated of Crash at Front

Estimated impact locations of frontal crash

ImpctLocnEstimdOfCrashAtLe

Impact Location Estimated of Crash at Left

Estimated impact locations of left side crash

ImpctLocnEstimdOfCrashAtRe

Impact Location Estimated of Crash at Rear

Estimated impact locations of rear crash

ImpctLocnEstimdOfCrashAtRi

Impact Location Estimated of Crash at Right

Estimated impact locations of right side crash

IndcrDisp

Indicator Display

This port provides Indication to Instrument cluster of Left/Right turn indicator activation status.

0 Off

1 LeOn

2 RiOn

3 LeAndRiOn

IndcrOut

Indicator Output

This port provides request to Turn on or off the turn indicators

IndcrPat

Indicator Pattern

This port provides request to Set a pattern for flashing sequence

InjrH2Consold

Consolidated Value for Hydrogen injector

Hydrogen injector: Consolidated physical value, either a measured

value or a modeled value.

InjrH2Cpby

Capability for Hydrogen injector

Hydrogen injector: The dynamic instant capability.

InjrH2Outp

Output Value for Hydrogen injector

Hydrogen injector: Final controller output.

InjrH2Reqd

Requested Setpoint for Hydrogen injector

Hydrogen injector: Final requested physical setpoint.

InjrH2Sp

Setpoint Value for Hydrogen injector

Hydrogen injector: Final actuator setpoint.

IntrLiBriActvn

Interior Light Brightness Activation

The brightness of a light source is requested by a percentage value (independent of light actuator type and environment e.g. voltage of electrical system). It depends on the functionality when the light source shall be switched on.

IntrLiBriActvnOfAshtrayLiFrntCen

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfAshtrayLiFrntLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfAshtrayLiFrntRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfAshtrayLiGroup

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfAshtrayLiMidCen

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfAshtrayLiMidLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfAshtrayLiMidRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfAshtrayLiReCen

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfAshtrayLiReLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfAshtrayLiReRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfCbnLiFrntCen

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfCbnLiFrntLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfCbnLiFrntRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfCbnLiGroup

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfCbnLiMidCen

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfCbnLiMidLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfCbnLiMidRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfCbnLiReCen

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfCbnLiReLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfCbnLiReRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfCurbLiFrntLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfCurbLiFrntRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfCurbLiGroup

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfCurbLiMidLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfCurbLiMidRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfCurbLiReLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfCurbLiReRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfEngCmptmtLi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfExtrLiSwtIllmn

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfFootwellGroup

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfFootwellLiFrntCen

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfFootwellLiFrntLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfFootwellLiFrntRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfFootwellLiMidCen

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfFootwellLiMidLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfFootwellLiMidRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfFootwellLiReCen

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfFootwellLiReLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfFootwellLiReRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfGlvCmptmtLi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfIgnSwtIllmn

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfIntrLiGroup0

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfIntrLiGroup1

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfIntrLiGroup10

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfIntrLiGroup11

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfIntrLiGroup12

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfIntrLiGroup13

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfIntrLiGroup14

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfIntrLiGroup15

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfIntrLiGroup2

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfIntrLiGroup3

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfIntrLiGroup4

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfIntrLiGroup5

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfIntrLiGroup6

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfIntrLiGroup7

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfIntrLiGroup8

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfIntrLiGroup9

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForCigaretteLighterIllmnAtTrLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForCigaretteLighterIllmnAtTrRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForCigaretteLighterIllmnFrntCen

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForCigaretteLighterIllmnFrntLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForCigaretteLighterIllmnFrntRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForCigaretteLighterIllmnGroup

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForCigaretteLighterIllmnMidCen

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForCigaretteLighterIllmnMidLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForCigaretteLighterIllmnMidRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForCigaretteLighterIllmnReCen

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForCigaretteLighterIllmnReLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForCigaretteLighterIllmnReRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForDoorOpenerIllmnFrntLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForDoorOpenerIllmnFrntRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForDoorOpenerIllmnGroup

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForDoorOpenerIllmnMidLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForDoorOpenerIllmnMidRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForDoorOpenerIllmnReLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForDoorOpenerIllmnReRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForDoorSillIllmnFrntLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForDoorSillIllmnFrntRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForDoorSillIllmnGroup

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForDoorSillIllmnMidLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForDoorSillIllmnMidRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForDoorSillIllmnReLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForDoorSillIllmnReRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForReadingAtRowThrdCen

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForReadingAtRowThrdLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForReadingAtRowThrdRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForReadingFrntCen

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForReadingFrntLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForReadingFrntRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForReadingGroup

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForReadingReCen

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForReadingReLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForReadingReRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForSftyBltLockIllmnFrntCen

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForSftyBltLockIllmnFrntLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForSftyBltLockIllmnFrntRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForSftyBltLockIllmnGroup

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForSftyBltLockIllmnMidCen

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForSftyBltLockIllmnMidLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForSftyBltLockIllmnMidRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForSftyBltLockIllmnReCen

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForSftyBltLockIllmnReLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfLiForSftyBltLockIllmnReRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfSwtIllmnForHzrdWarn

Interior Light Brightness Activation of Hazard Warning Switch Illumination

Activation Of Interior Hazard Warning Switch Illumination (percentage value)

IntrLiBriActvnOfTrCmptmtGroup

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfTrCmptmtLiCen

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfTrCmptmtLiLoLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfTrCmptmtLiLoRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfTrCmptmtLiUpLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfTrCmptmtLiUpRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfVanityLiFrntLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfVanityLiFrntRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfVanityLiGroup

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfVanityLiMidLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfVanityLiMidRi

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfVanityLiReLe

Activation of Interior Light Source Brightness

The brightness of a interior light source is requested by the interior light manager. The percentage value (independent of light actuator type and environment e.g. voltage of electrical system) depends on the functionality that the light source shall be switched on. 100 percent means full power of the light actuator

IntrLiBriActvnOfVanityLiReRi

Activation of Interior Light Source Brightness
